HOMCOM 3 Piece Pub Table and Chair Set Assembly Manual (SKU:835-213V80WT)

The HOMCOM 3 Piece Pub Table and Chair Set combines modern design with functionality. Featuring a sturdy metal frame and clean panels, this set is perfect for dining areas, kitchens, or compact spaces. The straightforward assembly ensures ease of use, and with clearly labelled components, following the assembly steps in the right sequence will have your set ready in no time.

Warning & Safety Instructions

Before beginning the assembly process, please carefully read and follow these safety guidelines:

• Keep children and pets away during assembly.
• Ensure all parts and hardware are present before starting.
• Do not use the product if any part appears damaged or defective.
• Assemble the table and chairs on a flat, stable surface.
• Place a soft cloth or cardboard underneath to prevent floor scratches.
• Adult assembly is required.
• Do not exceed the maximum weight capacity of the table or chairs.

Unboxing Your Set: What’s Included

Parts List

Hardware List

Step 1: Assemble the Table Side Frame

1. Position the Table Legs: Place the Side Table Frames (2) upright on a flat, stable surface. Position them parallel to each other, as shown in the diagram.
2. Attach the Table Apron: Insert the Table Apron (3) between the upper inner sections of the frame, aligning the pre-drilled holes. Ensure both sides are correctly positioned.
3. Secure the Parts with Screws:
   • Insert the M6*55 Screws (A) through the pre-drilled holes of the Side Table Frames (2) and the Table Apron (3).
   • Use the M6*12 Screws (C) to secure additional points where indicated, ensuring the structure is stable.
4. Tighten the Screws: Use the Allen Key (F) to tighten all screws. Be sure to tighten evenly without overtightening to maintain proper alignment.

Step 2: Attach the Table Top Panel

1. Position the Table Top: Place the assembled table frame onto the Table Top Panel (1), ensuring it sits evenly on all sides.
2. Align the Holes: Align the pre-drilled holes on the underside of the Table Top Panel (1) with the holes on the table frame.
3. Secure the Table Top:
   • Insert M6*50 Screws (E) into the aligned holes around the perimeter of the table top.
   • Tighten each screw evenly to secure the Table Top Panel (1) firmly to the table frame.

Step 3: Attach the Chair Back Frame to the Aprons and Spindles

1. Position the Chair Aprons: Place the Chair Apron (6) pieces on a flat, stable surface.
2. Align the Chair Back Frame: Take the Chair Back Frame (4) and align the pre-drilled holes on the top part of the frame with the corresponding holes on the Chair Apron (6) pieces.
3. Attach the Chair Back Frame:
   • Insert M6*35 Screws (B) through the aligned holes to attach the Chair Back Frame (4) to the Chair Apron (6) and Spindle (7).
   • Tighten securely using the Allen Key (F), ensuring the frame is firmly connected to the aprons.
4. Insert the M6*12 Screws:
   • Insert M6*12 Screws (C) through the Chair Apron (6) to the Chair Back Frame as shown in the pic.
   • Use Allen Key (F) to tighten it.

Repeat for the second chair.

Step 4: Attach the Frame to the Chair Front Frame

1. Align with the Chair Front Frame:
   • Take the Chair Front Frame (5) and align it with the Chair Frame Apron (6) and Spindle (4).
   • Ensure that the pre-drilled holes on the Chair Apron (6) and Spindles (7) align with the holes on the Chair Front Frame (5).
2. Attach the Chair Back Frame:
   • Insert M6*35 Screws (B) through the aligned holes on the Chair Front Frame (5) into the Chair Apron (6) and Spindles (7).
   • Tighten the screws securely with the Allen Key (F), ensuring the frames are firmly attached.
3. Insert the M6*12 Screws:
   • Insert M6*12 Screws (C) through the Chair Apron (6) to the Chair Front Frame (5) as shown in the pic.
   • Use Allen Key (F) to tighten it.
4. Final Check:
   • Ensure that the Chair Back Frame (4) and Chair Front Frame (5) are securely connected.

Repeat for the second chair.

Step 5: Attach the Chair Seat

4. Position the Chair Seat: Place the assembled chair frame onto the Chair Seat (8), ensuring it sits evenly on all sides.
5. Align the Holes: Align the pre-drilled holes on the underside of the Chair Seat (8) with the holes on the table frame.
6. Secure the Table Top:
   • Insert M6*30 Screws (E) into the aligned holes around the perimeter of the Chair Seat.
   • Tighten each screw evenly to secure the Chair Seat (8) firmly to the chair frame.

Repeat for the second chair.

Step 6: Attach the Chair Backrest

1. Position the Chair Backrest: Place the Chair frame upright and Align the pre-drilled holes on the Chair Backrest (9) with the corresponding holes on the Chair Frame.
2. Insert the Screws:
   • Insert M6*30 Screws (D) through the aligned holes to secure the Chair Backrest (9) to the frame.
   • Tighten each screw securely using the Allen Key (F).
3. Final Tightening:
   Ensure all screws are tightened evenly to firmly attach the Chair Backrest (9) to the chair frame.

Repeat for the second chair.

Step 7: Chair Assembly Complete

1. Final Chair Check:
   Both chairs should now be fully assembled, with the Chair Backrest (9) securely attached to the frame.
2. Inspect the Stability:
   Ensure that the Chair Backrest (9) is securely fastened and that all screws are tightened.
3. Place Chairs Upright:
   Position each chair upright on a flat, stable surface.
4. Check for Wobbling:
   Check that all four legs are in contact with the ground and that there is no wobbling. If necessary, retighten the screws for added stability.

Final Step: Complete Assembly

1. Place the Chair and Table Together:
   Position the assembled chairs next to the assembled table, ensuring they are properly aligned.
2. Final Check:
   Ensure that all components are secure and stable. Verify that the table is level and the chairs are positioned evenly around it.
3. Enjoy Your New Set:
   Your HOMCOM 3 Piece Pub Table and Chair Set is now fully assembled and ready to be used!

Troubleshooting Guide

Care & Maintenance

• Clean surfaces with a soft, dry or slightly damp cloth.
• Avoid using abrasive cleaners or harsh chemicals.
• Periodically check and retighten screws.
• Use the set indoors only and on level flooring.
• Avoid excessive moisture exposure.

With its sleek design and simple assembly, the HOMCOM 3 Piece Pub Table and Chair Set (SKU:835-213V80WT) is a practical addition to any space. Follow the instructions for optimal results and enjoy the comfort and style this set brings to your home.

You can also download this assembly manual for reference.
